Price range: £3,609.59 through £4,627.95 including v.a.t.
2375W, 24V, 7.0kWh Professional Off-Grid Solar System
This medium scale off-grid kit is ideal for applications such as, garages, workshops, garden offices and static caravans.
Looking for a grid-connected system, check out the 2200W On-Grid Solar Kit (6 Panels), or the 2200W On-Grid Solar Kit (6 Panels with Battery Option).
PLEASE NOTE: Due to erratic stock and current delivery issues, lead time is typically 1 – 2 weeks. If you have any queries please do contact us.
All of our kits designed for houses (on-grid and off-grid) are supplied with full instructions and telephone support, however a competent electrician should be used to make the final connection.
Kindly note that due to changes in shipping costs we are now charging a larger shipping fee on panels over 1m in length. Please contact us with any queries that you may have and we will be happy to help.
2375W, 24V, 7.0kWh Professional Off-Grid Solar System
This medium scale off-grid kit is ideal for applications such as , garages, workshops, garden offices and static caravans. In UK summer conditions this system could generate approximately 15.0kWh per day. This system includes a 3000Va (2400w) inverter charger.
The 2375W, 24V, 7.0kWh Professional Off-Grid Solar System includes the following components:
5 x 475w domestic solar panel – Panel model may vary depending on availability
1 x Victron EasySolar-ii GX 24/3000 solar inverter charger
1 x DC isolator switch
5 x Aluminium L shape mounting brackets (set of 6)
1 x MC4 type connectors (1 pair, male & female)
4 x Stud-Type Battery Terminal Clamp
1 x 150a Mega fuse and fuse holder
1m of 50mm single core tri rated cable – Red
1m of 50mm single core tri rated cable – Black
4 x Rolls S6 460 (6v 415ah) AGM batteries
1 x Battery isolator switch
60 meters of 4mm single core solar cable
6 x Cable lugs (2 x 50/10, 4 x 50/8)
Batteries can be upgraded to 1x Fogstar 24v 280ah lithium battery for 6.7kWh usable capacity.
Please note that that the mounts supplied are basic aluminium L-shape brackets. For tiled or corrugated roof surfaces different mounting options will be needed. Please email [email protected] if you need different mounting options for your kit.
Pre-wired Option:
Option includes a 1.2m x 1.2m board with your solar kit mounted upon. Built up here in our workshop prior to delivery. Wired, tested and ready to go. Our pre-assembled plug & play kits will remove much of the DIY element of our off grid kits.
Leaving you to simply
- Mount the solar panels.
- Wire up your solar panels to the pre-assembled board using the simple pre-wired cables.
- Connect the batteries.
PLEASE NOTE: Due to erratic stock and current delivery issues, lead time is typically 1 – 2 weeks. If you have any queries please do contact us.
| Would you like our pre assembled service? | YES, NO |
|---|
