24v Victron Phoenix Inverter:
24v DC to 230v AC Pure sinewave output, high peak power and high efficiency.
Combined high frequency and line frequency technologies ensure the best of both worlds.
24v Victron Phoenix Inverter:
SinusMax – Superior engineering
Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of
applications. The design criteria have been to produce a true sine wave inverter with optimized
efficiency but without compromise in performance. Employing hybrid HF technology, the result is a
top quality product with compact dimensions, light in weight and capable of supplying power,
problem-free, to any load.
Extra start-up power
A unique feature of the SinusMax technology is very high start-up power. Conventional high
frequency technology does not offer such extreme performance. Phoenix inverters, however, are
well suited to power up difficult loads such as computers and low power electric tools.
To transfer the load to another AC source: the automatic transfer switch
For our lower power models we recommend the use of our Filax Automatic Transfer Switch. The
Filax features a very short switchover time (less than 20 miliseconds) so that computers and other
electronic equipment will continue to operate without disruption.
LED diagnosis
Remote on/off switch
Connector for remote on off switch available on all models.
Specification:
DC Voltage: 24v
Output Power: 110v AC / 230v AC
Continuous Power: 250w / 375w / 500w / 800w / 1200w
Peak Power: 500w / 700w / 1000w / 1600w / 2400w
Max Efficiency: 94%
Zero Load Power Consumption: ~4w
Low Battery Alarm: Yes
Low Battery Shutdown: Yes
Low Battery Auto Recovery: Yes
Operating Temp Range: -40 to +50 degrees C
Protection rating: IP20
For full specs please download file
Delivery time 3-5 days on all orders
| Weight | 6500 g |
|---|
