£37.98 including v.a.t.
EP Solar View Star AU Series 10A 12/24v Solar Charge Controller with LCD Display & Twin USB output:
ViewStar AU series is a PWM charge controller with built in LCD display & twin USB outputs. If monitoring data is required for your system then the Viewstar range is the best choice. The View Star A series solar charge controller has an easy to use 2 button intuitive interface and is able to charge either 12v or 24v batteries. Gel, Sealed, and Flooded battery types are independently selectable, plus temperature compensation. Both features result in greater battery charging efficiency and better battery life time.
Kindly note that due to changes in shipping costs we are now charging a larger shipping fee on panels over 1m in length. Please contact us with any queries that you may have and we will be happy to help.
EP Solar View Star AU Series 10A 12/24v Solar Charge Controller with LCD Display & Twin USB output:
ViewStar AU series is a PWM charge controller with built in LCD display and twin USB outputs. If monitoring data is required for your system then the Viewstar range is the best choice. The View Star AU series solar charge controller has an easy to use 2 button intuitive interface and is able to charge either 12v or 24v batteries. Gel, Sealed, and Flooded battery types are independently selectable, plus temperature compensation. Both features result in greater battery charging efficiency and better battery life time.
Fully safe with built in protection against over charging/reverse polarity/over current/high voltage and short circuits. Easy to fit with simple English instructions. Combining a compact size unit with EP Solar’s reliability makes this the full package when considering a complete charge controller.
Features：
·3-Stage intelligent PWM charging：Bulk, Boost/Equalize, Float
·Support 3 charging options: Sealed, Gel, and Flooded
·LCD display design, dynamically displaying device’s operating data and working condition
·Multiple load control modes
·Energy statistics function
·Battery temperature compensation function
·Extensive Electronic protection
Electronic Protections：
·PV short circuit protection
·PV reverse polarity protection
·Battery over voltage protection
·Battery over discharge protection
·Battery reverse polarity protection
·Load overload protection
·Load short circuit protection
·Battery overheating protection
·Controller overheating protection
– 5VDC/2.4A (Total)
Specification:
Max Solar Voltage: 25v (12v system) 50v (24v system)
Battery voltage range 9-17v / 16-32v (12v/24v)
Rated Battery Current 10A
Terminal size: 4mm
Operating temp: -25 to +55 centigrade
Dimensions: 142mm x 85mm x 41.5mm
Weight: 220g
